Spesifikasi
Operating frequency range: dari 1 hingga 10,0 MHz
Range of measured time intervals (duration of scanning): dari 6 hingga 1000 µs
Velocity range: 1000 – 9999 m/s
Error of measurement of time intervals: tidak melebihi ± 0,025 µs
Maximum permissible error of measurement of the amplitudes of the signals at the receiver input in the range from 0 to 110 dB: tidak melebihi ± 0,5 dB
Testing gain range: 125 dB
Averaging over the quantity of starts: dari 1 hingga 16
Range of variation of temporal sensitivity adjustment (TVG): 40 dB
Number of control points TVG: 16
Duration of the excitation pulse to the load: dari 0,0 hingga 0,5 µs
Deviation of the amplitudes of input signals in the range from 10 to 100% of the screen height not more than: 1 dB
Setting a delay in the prism of the probe: dari 0 hingga 15 µs
Detection of signals: positive half-wave, radio mode
Standards:
EN 12668
ASTM E1324
EN 55011
EN 61000-6-2:2001
EN 61010-1:2014 (EN 61010-1:2010)
EN 60529:2014
EN ISO 16810:2016
SOU NNEC 027:2014
SOU NNEC 032:2014
SOU NNEC 038:2017
Dimensions (WHL): 140 mm x 210 mm x 55 mm
Weight, not more: 1,5 kg
Package:
Weight, not more – 4,5 kg
Dimensions – 40259 cm
