Spesifikasi
Brinell scales and loads:
HBW 2.5/62.5
HBW 2.5/187.5
HBW 5/62.5
HBW 5/125
HBW 5/250
HBW 5/750
HBW 10/100
HBW 10/250
HBW 10/500
HBW 10/1000
HBW 10/1500
HBW 10/3000
Test forces:
62.5 kgf (612.9 N)
100 kgf (980.7 N)
125 kgf (1226 N)
187.5 kgf (1839 N)
250 kgf (2452 N)
500 kgf (4903 N)
750 kgf (7355 N)
1000 kgf (9807 N)
1500 kgf (14710 N)
3000 kgf (29420 N)
Measurement error:
≤125 HBW: ±3.0 %
125<HBW≤225: ±2.5 %
225 HBW: ±2.0 %
Hardness test range: 8 ~ 650 HBW
Test materials:
Structural steel dengan kekerasan rendah, sedang, hingga relatif tinggi
Non-ferrous metals dan alloy
Logam lunak seperti timah, aluminium, dan timbal
Hardened steel, alloy, dan casting dari logam non-ferrous
Soft alloy bearings
Size and requirements to test objects:
Objek yang tebal dan besar dengan permukaan kasar seperti bagian berkarat atau permukaan hasil pengerjaan kasar
Scales conversion:
Otomatis ke skala Rockwell dan Vickers
Indenter balls:
2.5 mm
5 mm
10 mm
Microscope magnification: 20x
Microscope resolution: 0.005 mm
Maximum height of the test object:
185 mm (opsional hingga 500 mm)
Maximum depth of the test object:
135 mm (opsional hingga 200 mm)
Data output:
Digital LCD display
RS-232
Printer (opsional)
Type: Digital, elektronik
Dwell time: 5–60 detik, dapat diatur
The power source and the voltage: AC 220V ± 5%, 50–60 Hz
Dimensions: 550 x 210 x 750 mm
Net weight: ~130 kg
Gross weight: ~140 kg
Color: Biru
